Kit 75 - 633 Alu Kite Freeride

Kit 75 - 633 Alu Kite Freeride K75A633


This full carbon wing with its low aspect 3.3 AR, moderate inverted gull wing, concave bottom design will take your foiling experience to the next level at a very affordable price. The 633 combined with the 483 stabilizer permits you to foil from walk speed up to 25 knots.

The 633/483 combo is the choice for all those riders aiming to learn new manouvers, surfing small waves and who want to progress their abilities. This wing will permit you to enter the water with 1 or 2 sizes smaller kite. The 75 cm aluminum mast makes it suitable even for beginners.

A second 95 cm mast is available at only 99 euros, the W679, W790, W873 and the new W1100 front wings are the perfect complement for those riders who want to use this foil with surf, sup, windwing or kite.


Out of stock



Kit 75 - 633 Alu Kite Freeride specs
LIFT SPEED 9/10
CONTROL 7/10
AGILITY 9/10
UPWIND 6/10
TOPSPEED 7/10
characteristics
Best For
Evolution
Suggested For
WaveRiding
Water Surface
Choppy - Glassy
Wind
Light - Medium
Level
Beginner - Intermediate
Weight
75 - 85 Kg

Pack content
1 x M75A - Aluminium Mast 75 Alu
1 x MHW034 - Plate Adaptor Kite Alu
1 x FS710A - Fuselage 710 Alu
1 x W633 - Carbon Front Wing 633mm
1 x S483 - Carbon Stabilizer 483mm
2 x Flat Head Screws M8x40
2 x Socket Head Screws M8x40 and washers
1 x Flat Head Screws Torx M6x16
1 x Flat Head Screws Torx M6x20
3 x Flat Head Screws Torx M6x30
Grease, torx
Instructions

DIMENSIONS & ADVANCE SPECS
Mast Height
750 mm

Front Wing
633

Front Wing Span
633mm

Front Wing Root Chord
256 mm

Front Wing Aspect Ratio
3.3

Front Wing Surface
1239 cm2

Stabilizer
483

Stabilizer Span
483 mm

Stabilizer Root Chord
85 mm

Stabilizer Aspect Ratio
7,6

Stabilizer Surface
316 cm2
